Why does silicon nitride play an essential role in chips? Examine the advantages of silicon nitride compared to other products.

In chip manufacturing, there is a product that plays an essential function, that is silicon nitride (SiNx). Although it may not obtain the exact same interest as various other much more well-known semiconductor materials such as silicon (Si), gallium arsenide (GaAs) or gallium nitride (GaN), its value is self-evident. Most chips will use this material.

(Application of silicon nitride in chips)
1. Why is it SiNx?

Mindful friends have seen that I made use of SiNx when creating the chemical formula of silicon nitride. Pals who have actually studied high school chemistry need to know that N is the 5th major team aspect. Realistically, the valence ought to be -3, while the chemical valence of silicon is +4. The chemical formula of silicon nitride ought to be Si3N4. Exactly how can it be SiNx?

First, let’s speak about the multivalent state of nitrogen: nitrogen has several valence states, mostly because it has 5 valence electrons, and nitrogen atoms can share these electrons in different means. Nitrogen can develop different valence states, which generally rely on the number of electrons it shows to various other aspects.

For nitrogen, its most secure valence state is -3, such as in ammonia (NH3) and gallium nitride (GaN). Nevertheless, nitrogen can additionally develop a favorable valence state by losing electrons, such as the +5 valence state in nitric acid (HNO3). In addition, nitrogen can likewise form a valence state in between -3 and +5, such as the +3 valence state in nitrous acid (HNO2) or the +1 and +2 valence states in some organic compounds.

Secondly, allow’s discuss silicon nitride:

In the semiconductor industry, silicon nitride used in various applications is often non-uniform, usually stood for by SiNx. SiNx is an amorphous product whose homes depend upon the proportion of nitrogen to silicon, that is, the worth of x. When the value of x changes, the physical and chemical buildings of silicon nitride will likewise transform. Silicon nitride does can be found in several forms, including Si3N4, Si2N2, WRONG, and so on

( structure of Si3N4)

Si3N4 is a crystalline material, which suggests that its silicon and nitrogen proportion is fixed. When the value of x amounts to 4/3, SiNx is equal to Si3N4. Nonetheless, in functional applications, SiNx is often non-uniform, and its silicon and nitrogen proportion can be regulated by changing the criteria of the PVD or CVD procedure.

2. What is the role of SiNx in chip production?

Silicon nitride has exceptional insulation residential properties, and its resistivity can be as high as 10 ^ 14 Ω · centimeters, much surpassing some usual insulating products such as silicon oxide (SiO2). Its reduced dielectric continuous makes it an ideal seclusion layer in microwave and RF applications. The silicon nitride layer also plays a role in obstructing the diffusion of pollutants in the chip. It can prevent dopants such as boron and phosphorus from transforming tool features via diffusion. Furthermore, it can additionally protect against the diffusion of metal ions to stop faults such as short circuits.

The superb thermal stability of silicon nitride is established by its unique chemical residential properties and crystal structure. It can continue to be steady in a high-temperature environment without chemical disintegration or physical form adjustments like various other products. That’s because in the crystal framework of silicon nitride, each silicon atom is combined with 4 nitrogen atoms in the kind of a tetrahedron, and each nitrogen atom is also combined with four silicon atoms in the type of a tetrahedron. This structure makes the crystal latticework of silicon nitride very steady and challenging to flaw. Consequently, it is used as a gate-insulating layer when making high electron wheelchair transistors (HEMTs).

( role of SiNx in chip manufacturing)
3. What are the benefits of SiNx over SiO2?

Much better thermal security, more challenging hardness, and harder to etch.
